A powerful performance. Go for XS WIRLESS 1 and rely on a solid wireless transmission with up to 10 compatible channels in a stable UHF band.
The XS WIRELESS 1 BRASS SET is an easy to use all-in-one wireless system, especially designed to provide a powerful
live sound for brass instruments. The set includes an intuitive stationary receiver for quick set-up and hassle-free handling, as well as a compact bodypack transmitter and a rugged condenser gooseneck microphone.

חלק קדמי:


חלק אחורי:


Specifications

approx. 200 x 42 x 127 mm

approx. 340g

Receiver: 12 V DC nom. / 300 mA

Receiver: 50 to 16,000 Hz (–3 dB)

approx. 71 x 96 x 28 mm

approx. 95g

Transmitter: 2 AA size batteries, 1.5 V

0 to -30 dB, adjustable in 10 dB steps

condenser

≤ 0.9%

cardioid

≥ 103 dBA

10 mW

up to 24 MHz

approx. 10 hrs

wideband FM

1/4“ (6.3 mm) jack socket (unbalanced): +6 dBu, XLR socket (balanced): +12 dBu

rugged ABS housing

8 frequency banks, each with up to 10 factory-preset channels

A: 548-572 MHz, GB: 606-630 MHz

B: 614-638 MHz

C: 766-790 MHz

D: 794-806 MHz

E: 821-832 MHz, 863-865 MHz

K: 925-937.5 MHz

< 3 μV at 52 dB(A)rms S/N

147 dB

adjustable from 3 dBμV to 28 dBμV (combined with pilot tone)

2.4 GHz, Low Power OQPSK (only active during synchronization)

1.5 mV / Pa

45 dB, adjustable in 5-dB steps

20 dB, switchable

operation: 0°C to +40°C, storage: –20°C to +70°C

double superheterodyne

antenna switching diversity via internal antennas
