Description
מיקסר לקלידים Radial Key-Largo עם 3 ערוצי סטריאו אנלוגיים לחיבור מגוון קלידים בו זמנית. חיבור דיגיטלי USB ו- MIDI I/O לשליטה על soft-synths.
נתונים טכניים
- Audio Circuit Type: Active circuit with audio-grade operational amplifiers
- Number of Channels:
- 3 x Stereo analog inputs
- 1 x Stereo USB input
- 2 x Stereo analog outputs
- Frequency Response: 20Hz to 20kHz (+/-0.5dB)
- Noise Floor: -91dBu
- Clip Level – Input: +12dBu
- Clip Level – Output: +24dBu
- Maximum Gain – Input to Output: +12dBu
- Total Harmonic Distortion:
- Input Impedance:
- Analog Inputs: 20k Ohms
- FX Return: 50k Ohms
- Volume Return: 485k Ohms
- Output Impedance:
- XLR: 300 Ohms
- 1/4”: 450 Ohms
- FX Send: 1k Ohms
- Volume Send: 300 Ohms
- Controls – Boost:
- Input level CH 1-3
- USB input level
- EFX send/receive
- Main/monitor output level
- Switches:
- Momentary sustain
- Effects on/off
- Effects mono/stereo
- Ground lift
- Sustain closed/open
- USB assign
- Effects Loop: 1/4” send and return jacks
- LED Indicators: Large 3mm OD ultra-bright LEDs
- Construction: 14-gauge steel
- Finish: Durable powder coat
- Power: 260mA, 15VDC (centre-positive)
- Conditions: For indoor use at temperatures between +5°C and +40°C
- FCC Approval: Complies with section 15 of the FCC rules
- Dimensions:
- Length: 213mm / 8.4”
- Width: 127mm / 5”
- Height: 48mm / 1.9”
- Weight: 1.47kg / 3.25lbs
